Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity

    Buy cheap Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity from wholesalers

    Buy cheap Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity from wholesalers
    • Buy cheap Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity from wholesalers

    Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity

    Ask Lasest Price
    Brand Name : SINOWAY
    Model Number : SWGC16042C10
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 set per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Automatic Waste Disposal Truck / Recycle Garbage Truck 400L Fuel Tank Capacity

    DONGFENG 4×2 Chassis 10m3 Capacity CUMMINS Engine of Garbage Truck Sanitation Vehicle


    Garbage compactor truck ,also called compactor garbage truck , garbage truck for sale , trash compactor , compression garbage truck , refuse truck , garbage collection vehicle, waste truck container garbage truck, compact garbage trucks, waste compactor trucks, compactor garbage truck for sale etc


    Garbage compactor truck capacity from 3 cbm to 18cbm all available .


    SINOWAY brand Garbage compactor truck advantage :

    1 Dual operation both at the rear of compactor garbage truck and inside cabin , easy control

    2 Famous brand hydraulic pump to drive hydraulic valve to keep garbage compactor truck safety

    3 Cheap price , one year warranty

    4 Garbage bin lifting system could design as customer’s requirement .

    5 Lock system is operated by machinery hydraulic system can reduce second pollution mostly.

    6 High compression ability, huge loading quantity. Compress the garbage of 200-400 kg/m3 into 400- 600 kg/ m3

    7 Most process are operated automatically, and the system is equipped with interlock devices to prevent Error operation.
    8 Hydraulic system& Electric system control all kinds of movements of the compressor truck, so to prevent getting stuck, intervention or collocation of two parts.
    9 Automatic design, saving labor, energy conservation and environment protection.


    Engine
    ModelCummins B170 33
    TypeSix cylinders,four strokes, direct injection turbocharged, water cooled
    Rated power125kw (170Hp)
    Main Technical Specifications
    Kerb mass9295Kg
    Payload10000Kg
    G.V.W19295Kg
    Max. speed85Km/h
    Approach angle34°
    Departure angle18°
    Crew3
    Hopper capacity10m³
    Volume of pluggerI.3m³
    Loading time≤ 20s
    Unloading time≤ 30s
    Max. pushing force for garbage150Kn
    Max. compression force400Kn
    System pressure16Mpa
    Mode of drive4 x 2
    Fuel tank capacity400 L
    Transmission System
    DF6S900T with synchronizer, 6 forward and 1 reverse
    Ratio
    Forward6.446, 3.841, 2.29, 1.477, 1.00, 0.802
    Reverse5.802
    Steering System
    Hrdraulic steering with power assistance
    Axle and Tyre
    Front axle3.6T
    Rear axle9T
    Tyre size9.00R20 Radial tyre
    Dimensions
    Overall size (L x W x H)7640 x 2480 x 3150mm
    Wheel base3950mm
    Clutch and Brake
    Service brakeFull air brake, dual circuit
    Parking brakeSpring energy operating on rear wheels
    Suspension
    Front suspensionTapered leaf spring 9 semi-elliptic leaf spring
    Rear suspensionTapered leaf spring 11 semi-elliptic leaf spring
    Optional
    Bin lifting system
