40 tph Mobile Asphalt Batching Plant For Road

    Buy cheap 40 tph Mobile Asphalt Batching Plant For Road from wholesalers

    Buy cheap 40 tph Mobile Asphalt Batching Plant For Road from wholesalers
    • Buy cheap 40 tph Mobile Asphalt Batching Plant For Road from wholesalers

    40 tph Mobile Asphalt Batching Plant For Road

    Ask Lasest Price
    Brand Name : SINOWAY
    Model Number : SWABP400M
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : D/A, L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 5 set per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    40 tph Mobile Asphalt Batching Plant For Road

    40 tph Mobile Asphalt Batching Plant For Road Construction Asphalt Mixing Plant


    1. Technical parameters
    Capacity40 tph
    Feeder hopper capacity1.2m3
    Concrete output1.2m3
    Aggregate size<=50mm
    Aggregate Bins3X5m3 each, accumulative scale
    AccuracyAggregate≤2000kg±3%
     Fly ash≤180kg±2%
     Bitumen≤180kg±2%
    Product temperature120~165 Celsius degree,adjustable
    Total consumption125 kW (Oil burner)
    Mill Power30kW (Coal burner)
    Coal requirement1.Volatile Percentage≥25%
    2.Low heat value≥6500kcal/kg
     3.Melting point 1500℃
     4.Moisture≤3%
     5.Powder percentage≤12%
     6.Diameter≥100mesh

    2. Supplies
    ItemDescriptionSpecificationUnit
    1. Aggregate dosageAggregate hopper5m33units
     Opeing device 6units
     Weighing hopper2000kg±3%1unit
     SensorTSC-2000kg3units
     Solenoid valve14423units
     Cylinder160×2003units
     Framework 1set
     Electric rollerØ500-750-1.31-7.5kW1unit
     Collecting belt650×17.9m1set
     Tension device 1set
     Roller 1set
     CleanerAlloy B8001set
    2.BurnerBurner 1units
     Blower1units
     Blower motorY2-160M1—11KW-21units
     Main oil pumpCB-13 ,1.1kW1sets
     Triangle beltA7871units
     High pressure oil pumpCB-6 ,0.55kW1sets
     fire-resistant brick 1sets
     electronic ignition system 1units
    3.DryerDrying drum(Ø2100mm)16Mn alloy steel1units
     Big gear loopZG310-5701units
     Decelerate caseZQ350-8.23-11units
     MotorY2-180M-15KW-41units
     Triangle beltC17532units
     Seal looplynbrath seal2units
     Frequency inverter 1units
    4.Aggregate elevator systemtrail and skip 1sets
     Feeder bucket device 1units
     ReducerBWY27-29-7.5kW1units
     Limit switchXCE-1453units
    5.Filler scaleWeighing hopper180kg±2%1unit
     screw conveyorØ219-4m-3kW1unit
     ReducerXLD4-9-31unit
     SensorTSC-300kg1unit
     Cylinder80×2002units
    6.Bitumen ScaleWeighing tank180kg±2%1unit
     Bitumen pump MotorY112M-5.5,N=4kW1unit
     Bitumen pumpCLB2001unit
     Pipelines 1set
     antiflow device 1unit
     SensorCST300kg1unit
     Cylinder80×501unit
    7. MixerMixer1.2m3,Twin-shaft type1unit
     ReducerXWDY9-17-22kW2units
     Hand-operated oil pump 3sets
     Upper cover 1unit
     Wind gate Cylinder80×1001units
     Cylinder125×2502units
     Waiting hopper 1unit
     Cylinder80×2501unit
    8.Finished elevator systemstorage bin9t1unit
     trail and skip 1set
     ReducerBWY27-21-7.5kW1unit
     Cylinder125×2001units
     Limit switchXCE-1453units
    9.Dust collecting systemCyclone filterlevel one1unit
     VentY5-47NO6C1unit
     Vent motorY160M1-18.5kW-21unit
     Clean dust motorY2-100L-1.1KW-41unit
     Worm reducerWPS70-1:301unit
     screw conveyor 1unit
     Cylinder50×801unit
     Pipeline and chimney 1set
    10.FrameworkChassis 1sets
     Front,rear axleFront tire:825-12×4pc1set
     Jacks(Support)10t6units
     Outside Staircase 1set
    11. Air SystemAir compressorW-0.9/7.5kW1set
     Pipelines 1set
     Solenoid valve 1set
     3-way connecting kitsQLGWC-L153units
    12. Control SystemControl room3m×2.5m×2m1unit
     Touch screenMT506T1unit
     Control panel 1unit
     Electronic cabin 1unit
     Cable 1set
     PLC 1set

    3.Optional:
    ItemDescriptionSpecificationUnit
    1.Coal-milling machine (Coal burner)Mill motor30kW1units
     Worm reducerWPA60-20:11units
     Speed frequency inverterEV3-1.5kW1units
     Speed Motor1.1kW-41units
     Coal pipeØ1501units
    2.Bitumen tank 40m31
    3.Level two dust filter systemWashery dust filter 1
     Bag dust filter 1
