    Mining Processing Equipment Hydrocyclone

    Ask Lasest Price
    Brand Name : SINWOAY
    Model Number : XC II F 375
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, L/C, D/A, D/P
    Supply Ability : 500 sets per year
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Mining Processing Equipment Hydrocyclone

    Mining Processing Equipment Hydrocyclone The Compound Hydrocyclone Hydraulic Cyclone

    Hydrocyclone is a common classification beneficiation equipment, with unique structure design adopts the composite structure of multi section type column body. It changes the height of column according to the need. If the height increased, overflow fineness increase up to about 10 μm diameter. Each diameter has unique cylinder length and cone angle, which can achieve the maximum tangential velocity at the minimum total cyclone length, so as to increase centrifugal force and improve the classification efficiency.


    Features and technology advantages

    1.The way of involute feeding through the inlet branch reduces the turbulence of the burst emanative flow when materials entry, makes a smooth movement of liquid inside cyclone, therefore gives a sharp classification.

    2.The rational length proportion of column and cone and reasonable insert depth of vortex finder.

    3.Wear resistant rubber as liners prolongs the service life by 2-4 times.


    Working principle

    The working principle of hydrocyclone is centrifugal sedimentation, when two phases or three phases mixed liquid is fed into hydrocyclone by a certain pressure liquid and produces strong three-dimensional-elliptic rotational movement. Due to the different density of particles, the centrifugal force, the centripetal buoyancy and drag force are different. So most coarse particles or heavy phase are discharged from cyclone underflow outlet, and the fine particles or light phase from the overflow tube, so as to achieve separation.


    Specification

    ModelSpec.Processing Capacity (m3/h)Partition Size (μm)Diameter of Overflow Port (mm)Diameter of Dust- Setting Nozzle (mm)Inlet Pressure (MPa)
    XC II F15015010 ~2325 ~7430 ~508~220.06 ~0.15
    XC II F 20020017 ~3828 ~8040 ~6516 ~32
    XC II F25025024 ~5330 ~8265~10016 ~40
    XC II F 30030040~10036 ~9065~12020 ~40
    XC II F 35035056~11840~10080~12030 ~70
    XC II F 37537574~15742~10590~13530 ~70
    XC II F 45045090~19244~110100~15030 ~70
    XC II F 500500128~30050~115130~22035~100
    XC II F 550550155~36852~120140~24035~100
    XC II F 600600200~46857~125160~26065~110
    XC II F 660660237~52460~130180~28080~150
