    15 ton River Dredging Equipment platform Swamp Cargo Carrier Soft terrain Transporter

    Earth Moving Equipment
    Amphibious swamp transport vehicle is a special kind of vehicle used for transportation of people or equipment in soft terrain and marsh areas.
    Sinoway SWSC150 amphibious swamp transporter is specifically designed to manoeuvre in marshy, swampy area and soft terrain, and it can also float on water as an added safety feature. It is completely self propelled and can virtually access all terrains. Amphibious transporters consist of an
    undercarriage and an upper structure with cabin, engine and platform.It can be equipped with winches and cranes according to different working conditions. At the same time, it can be refitted into swamp drilling platforms
    according to the situation. The machine can be custom-made to suit your needs too.
    Main Features
    Equipped with Cummins engine with good performance and reliability.
    Multi Synchronous Drive System
    Proprietary multi-synchronous drive motor design.Motors are mounted on front and rear of each pontoon.It offers superior tracking power as compared to a single motor design. A similar concept that is applied to a full time 4x4 gear system of a land vehicle.
    Amphibious Modular Design
    Designed to be easily transported by low bed trailer. Amphibious modules and attachments are designed to be able to fit into
    40ft container. Both the assembly and disassembly processes can be achieved in under 3 hours if equipped with proper tools and crane.
    No special tooling is required for the assembly and disassembly process.
    Each pontoon has 3 watertight compartments and manhole.The track system (shoe, chain, roller, pin and bushing) is extremely
    controlled tight tolerance. The track shoe supported by multiple stands of track chains provided the advantage of uniform pulling force
    and superior weight distribution across each track shoe. The shape of shoe is optimized to generate the powerful thrust force under water
    and driving force on the ground also.
    Driverr cabin
    Operater cabin is supported with innovative silicone rubber shock absorber, which minimize the shock brought by the rough terrain and engine or hydraulic vibration and impact transmitted to the cabin, increase the stability of cabin and improve the operators’ sitting quality and operating comfort.
    Main Technical Specification
    Operating weight40 ton
    Max. payload15 ton
    EngineCummins
    Type6-cylinders, water cool, turbocharging
    Rated power325hp/2200rpm
    Max. pressure320MPa
    Max. flow2×360L/min
    Main pumpDoosan
    Multi-way valveDoosan
    Control valveDoosan
    Travel motorDoosan
    Travel speed on land0~3.0km/h
    Travel speed on water0~1.0km/h
    Grade ability30°
    Hydraulic winch’s max pulling force20ton
    Hydraulic winch’s total rope length50m
    Ground pressure0.125Kgf/cm2
    Overall size (L×W×H)10200×6200×3500mm
    Width of pontoon/length of pontoon2400mm/1800mm
    Platform size (L×W×H)8500×6000×2000mm
    CabinAll-steel broad cab, 360 visual angle,
    centralized control operator panel, ratating chair, air conditioner
    Crane With Foldable Arm
    Crane capacity8ton
    Max. lifting range9.7m
    Max. lifting moment160kN.m
    Max. lifting height12.3m
    No. of telescopic arm sections3pcs
    Rotary rangePros and cons to 360°, continuous rotaion ≤3r/min
