Sinoway SWEA150 amphibious excavator/marsh buggy is specifically
designed to manoeuvre in marshy, swampy area and soft terrain, and
it can also float on water as an added safety feature. It is
completely self propelled and can virtually access all terrains,
and yet
requires minimum supporting transportation and hoisting equipment.
When fitted with a long reach front, the machine offers an
unparalleled package with unmatched productivity for your
investment.
Proven in projects like oil and gas industry, pipeline, land
reclamation, waterway deepening, delta works, etc., Sinoway team
takes every single chance to enhance our swamp buggy excavators'
reputation. Thus we have developed a complete line of swamp
excavator from 0.2m3 bucket, up to 1.1m3, with optional for long
reach boom amphibious excavator.
Main Features
Equipped with Cummins Isuzu or Doosan engine with good performance
and reliability.
Multi Synchronous Drive System
Proprietary multi-synchronous drive motor design.Motors are mounted
on front and rear of each pontoon.It offers superior tracking power
as compared to a single motor design. A similar concept that is
applied to a full time 4x4 gear system of a land vehicle.
Amphibious Modular Design
Designed to be easily transported by low bed trailer. Amphibious
modules and attachments are designed to be able to fit into
40ft container. Both the assembly and disassembly processes can be
achieved in under 3 hours if equipped with proper tools and crane.
No special tooling is required for the assembly and disassembly
process.
Supplementary pontoons can be added on each side to boost stability
in deeper water operation.
Spud piles attach to supplementary pontoons help to overcome
buoyancy effect, it offers added stability and enhanced
operability.
Pontoons are designed and built with provision for future addition
of supplementary pontoon and spud system.
Hydraulic Undercarriage Pontoons
Each pontoon has 3 watertight compartments and manhole.The track
system (shoe, chain, roller, pin and bushing) is extremely
controlled tight tolerance. The track shoe supported by multiple
stands of track chains provided the advantage of uniform pulling
force
and superior weight distribution across each track shoe. The shape
of shoe is optimized to generate the powerful thrust force under
water
and driving force on the ground also.
Driverr cabin
Operater cabin is supported with innovative silicone rubber shock
absorber, which minimize the shock brought by the rough terrain and
engine or hydraulic vibration and impact transmitted to the cabin,
increase the stability of cabin and improve the operators’ sitting
quality and operating comfort.
| Engine | |
| Model | Isuzu / Doosan |
| Type | Four-cylinder,water-cooled turbocharged,mechanical injection |
| Rated power | 57.6KW |
| Rated speed | 2200rpm |
| Main Technical Specification | |
| Operating weight | 15000Kg |
| Standard bucket capacity | 0.2m3 |
| Slewing speed | 12rpm |
| Stick digging force | 43.4KN |
| Bucket digging force | 49KN |
| Draw bar pull | 112.2 KN |
| Fuel tank capacity | 300 L |
| Hydraulic tank capacity | 140 L |
| Main Features | |
| Tracked pontoon structure | |
| Big torque travelling device | |
| Extendable chassis | |
| Big circular arc structure | |
| High capacity of fuel tank | |
| Main Applications | |
| River/Beach earth moving | |
| Swamp works | |
| Dredging applications | |
| Delta works | |
| Waterway deepening | |
| Hydraulic System | |
| Main pump | DOOSAN |
| Main valve | DOOSAN |
| Motor | DOOSAN |
| Hydraulic flow rate | 198L/min |
| Hydraulic pressure | 28MPa |
| Travelling System | |
| Travelling speed | 2.33~3.79km/h |
| Grade ability | 70% |
| Ground pressure | 0.013MPa |
| No.of chains | 2 |
| Dimensions | |
| Overall length | 9009mm |
| Overall width | 4500mm |
| Overall height | 3299mm |
| Ground clearance | 734mm |
| Length of pontoon | 6600mm |
| Width of pontoon | 1300mm |
| Height of pontoon | 1420mm |
| Optional | |
| Side pontoon | |
| Hydraulic spud | |
| Operating Scope | |
| Stick length | 3000mm |
| Boom length | 4500mm |
| A: Max. cutting height | 8443mm |
| B: Max. dumping height | 6457mm |
| C: Max. digging depth | 5879mm |
| D: Max. reach | 9000mm |
