    340HP Power Concrete Mixer Machine 10 Effective Capacity and Concrete Mixer Truck

    Ask Lasest Price
    Brand Name : SINOWAY
    Model Number : SWCM6410CH
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 50 units per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    340HP Power Concrete Mixer Machine 10 Effective Capacity and Concrete Mixer Truck

    Concrete Mixer Machine 10 Effective Capacity and Concrete Mixer Truck With 340HP Power


    Engine
    MakeSINOWAY
    TypeSix-cylinder, water-cooled, in-line, dry liner, direct-injection
    Max. power250kw
    Rated speed2100rpm
    Main Technical Specification
    Kerb weight12500kg
    G.V.W.33000kg
    Axle loading capacity (F/R)7500/2x16000kg
    Max. travelling speed90km/h
    Min. turning radius9m
    Gradeability30%
    Approach angle30°
    Departure angle24°
    Ground clearance255mm
    Fuel tank capacity320L (Galvanized steel)
    Dimensions
    Overall size (L x W x H)9100 x 2500 x 3980mm
    Wheelbase3200 + 1350mm
    Tread (F/R)2065/1860/1860mm
    Transmission System
    ZF tech. mechanical with synchronizer, 9 forward & 1 reverse
    Ratio
    Forward15.16, 11.26, 7.90, 5.67, 4.07, 2.76, 1.94, 1.39, 1,00
    Reverse12.26
    Mixer Drum
    Geometric volume of mixing drum16.7³
    Effective capacity10m³
    Rotation speed0-15rpm
    Feeding speed≥ 2.7³/min.
    Discharging speed≥ 1.2³/min.
    Residue rate≤ 1.0%
    Loading rate60.0%
    Inclination of mixing drum12.5°
    Materials for mixing drum16MnCu
    Model/brand/origin of pumpA4VTG90/Rexroth/Germany
    Model/brand/origin of reducerP4300/ZF/Germany
    Axle and Tyre
    Front axleStub axle with double T-cross section
    Rear axleDouble reduction with hub reduction and final drive
    Ratio5.73
    Tyre size13R22.5
    Rim size9.75 - 22.5
    Clutch And Brake
    Single-plate dry coil-spring clutch, hydraulically operated with air assistance, diameter 430mm
    Service brakeFull air brake, dual circuit
    Parking brakeSpring actuator at rear wheels
    Auxiliary brakeExhaust brake
    Steering System
    Driving positionLeft hand drive only
    TypeRe-circulation ball with integral power assisted by oil
    Suspension
    Front suspensionTapered leaf spring 09 semi-elliptic leaf spring
    Rear suspensionTapered leaf spring 12 semi-elliptic leaf spring
    Cab
    SINOWAY cab with A/C and CD
