    Compact Road Construction Equipment 3.5 ton Small Hydraulic Tandem Vibratory Rollers

    Ask Lasest Price
    Brand Name : SINOWAY
    Model Number : SWC203
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, L/C, D/A, D/P
    Supply Ability : 3000 units per year
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Compact Road Construction Equipment 3.5 ton Small Hydraulic Tandem Vibratory Rollers

    Building Construction Equipment

    Sinoway tandem road roller range covers from 0.77 ton for asphalt repairing work, to 14 ton tandem road roller with vibration for your extra heavy duty requirement. As our single drum road roller, both mechanical transmission and hydrostatic transmission tandem road roller are available. Our hydraulic tandem road roller is designed with dual amplitude and frequency, which will enable your compaction of difference layers of asphalt with the same high productivity as well as best effectiveness.

    SWC203 double drum vibratory roller is small-size tandem vibratory roller, applied to mending and maintaining various roads, expressway shoulder, side walk, parking area, sports ground and garden lawn, which is especially suitable for compaction of narrow areas as pipeline channel and drainage trench etc.

    Main Features

    The rear-drum travelled by side gear transmission and hydraulic vibration in front drum.

    Articulated frame with power steering, fork-type drum brackets with more than 600mm drum-side clearance.

    The gear-box uses Japanese technology with easy gearshift, three travel speeds posses good compaction and fast transportation.

    Platform trailer as option.

    Engine modelZN390Q
    Rated power22kw
    Operating weight3500kg
    Static linear load90N/cm
    Vibrating frequency45Hz
    Centrifugal force53kN
    Max. travelling speed1.95 / 7.15km/h
    Gradeability28%
    Turning radius4600mm
    Overall dimension3500 x 1390 x 2200mm
    Drum width1200mm
    Wheel base1686mm
